Carrier Tape Plastic Reel is an essential component used for packaging electronic surface mount components.
It consists of two parts: the carrier tape and the reel. The carrier tape is a continuous strip made of materials such as polystyrene or polycarbonate, with pockets or cavities for accommodating individual electronic components. The reel serves as the storage and transportation mechanism for the carrier tape.
The following is a detailed introduction to the Carrier Tape Plastic Reel:
Function: The carrier tape with components is wound onto the reel. Its design enables smooth unfolding during the manufacturing process, allowing the automatic soldering machine to pick up the components and place them onto the printed circuit board, thereby enhancing the efficiency and consistency of electronic equipment production.
- Size specification: The size of the reel is usually 7 inches, 10 inches, 13 inches, 15 inches, etc. Different sizes are compatible with different widths of the tape. For example, a 7-inch reel can be paired with 8mm tape, and a 13-inch reel can be paired with 32mm tape, etc.
.jpg)
- Material: The reels are generally made of anti-static materials such as PS and PC to ensure the safety of sensitive electronic components.
Type: It can be classified into anti-static type and non-anti-static type based on whether it is anti-static. Among them, the anti-static type tape reel is widely used and can effectively protect electronic components from being damaged by static electricity.
